XJ10
The company offers high-speed, high-precision, and highly stable fully automatic pick-and-place machines, such as the latest XJ-10 model. This advanced machine features an all-cast body structure, full linear motors, and a fully closed-loop control system. Additionally, it incorporates an optimized algorithm for enhancing the precision of placement head data tracking, significantly improving customers' ability to maintain accurate positioning during continuous mounting operations.
Category:
Keywords:
Products Detail
| Specification | XJ10 |
| Applicable PCB size | MIN 50*50mm |
| MAX 430*380mm | |
| Applicable PCB thickness | 0.5mm-3mm |
| Applicable components | 0201 Chip-L30*W30*10mm |
| Mounting capability | 10 |
| Mounting accuracy | ±0.05mm(XY) |
| Mounting speed | 40000 CPH(Optimum Speed) |
| Feeder capacity | 88 (8mm) |
| Feeder Type | Electric |
| Power supply | AC380/420/480, 3.5KVA |
| Air supply | 0.55MPa,150L/MIN |
| External dimensions | L 1310xW 1310xH 1575 mm |
| Weight | ≈1600KG |
| X-axis | Linear motor |
| Y-axis | Dual Linear Motor |
| Z-axis | High precision motor |
The above is the parameter of XJ10 new parts assembly production.
The company offers high-speed, high-precision, and highly stable fully automatic pick-and-place machines, such as the latest XJ-10 model. This advanced machine features an all-cast body structure, full linear motors, and a fully closed-loop control system. Additionally, it incorporates an optimized algorithm for enhancing the precision of placement head data tracking, significantly improving customers' ability to maintain accurate positioning during continuous mounting operations.
